Attach the included antennas to the rear panel of the transmitter. To improve the transmission
quality and to adapt to the spatial conditions they are rotatable and swivelling.
In case the space provided on the device for direct assembly of the antennas is not sufficient,
for example because the space on the rack is narrow, you can use the optionally available
coaxial cable to assemble the antennas separately from the device. For larger combinations
with up to four receivers, an antenna distributor is optionally available.
Connect one of the audio outputs of the receiver to your mixer or your amplifier. Ensure that
only one of the two outputs is ever used at a time, because faults might occur otherwise.
4.3 Transmitter
Open the lid of the battery compartment by sliding it in the direction of the arrow, and insert
the batteries. Pay attention to the correct location of the poles. Close the battery compartment
and switch the transmitter on. The "LOW BATT" LED briefly lights up.
Attaching the antennas
Connecting audio and starting
up
Inserting batteries into the
receiver
Installation and operation
UHF wireless system
18
