15 [GP]
Indicates the selected frequency group.
16 [CH]
Indicates the selected channel.
17
Indicates that the unit is locked to prevent unintentional operation.
18
Shows that the receiver has been muted.
19 [A/B]
Shows which of the two antennas is currently being used for signal transmission.
20 [SQ]
Shows the set squelch level for the radio signal. Setting the squelch too will lower the dynamics of the system.
21 [RF]
Shows the level of the radio signal received.
Connections and controls
UHF wireless system
26
