1 Ground, shielding
2 Signal (in phase, +)
3 Signal (out of phase, –)
A mini-XLR panel connector serves as a signal input on the transmitter. The figure and the
table show the mini-XLR pin assignment.
1 Ground
2 Positive signal (+)
3 Negative signal (–)
XLR plug (balanced)
Mini-XLR connections for signal
input on the transmitter
Plug and connection assignment
