TS 970 Transfer Switch
PM163 REV 0 20/02/05 39 Thomson Power Systems
NOTE
There are no user serviceable components located on the TSC 900
printed circuit board. If the TSC 900 controller (i.e. SCU or GHC) are
deemed to be defective, they must be returned to the Thomson Power
Systems Factory for repair or replacement. Please refer to Product
Return Policy section of this manual further information on product
return procedures required.
13.2. POWER CONTACTOR UNIT DRAWING
13.2.1. 100A – 400A POWER CONTACTOR (TYPICAL)
