Thomson Power Systems TSC 900 User Manual

TS 970 Transfer Switch
PM163 REV 0 20/02/05 16 Thomson Power Systems
6.3. POWER CONTACTOR REPLACEMENT (100-400A)
DANGER
Do not open equipment until ALL power sources are disconnected
Appropriate Personal Protective Equipment (PPE) must be worn before
handling heavy objects. Failure to do so may cause personal injury or death.
1. Using a flat screw driver, loosen screws holding the vinyl protector shown in the figure below.
2. Release the vinyl protector from the metal support basses by sliding it upwards, then pulling
outwards to disconnect.
STEPS 1 & 2
