THOMSON ETC009 - Page 10

ETC009 - ETC010
First issue 01 / 06
MODE 5
U0C300C 1 . 8 2005. 07 . 20-01
RADIO OFF
EQ BAR Equalizer Bar
BCFCHECK ON
MODE 5 : default value : 01000000
Bit 0,1,2,3,4 : No use
Bit 5 : Radio (FM Radio 0:OFF)
Bit 6 : EQ BAR (User menu display (0: bass & Treble; 1:Equalizer)
Bit 7 : BCF CHEK (Beam current protection 1:ON)
MODE 6
U0C300C 1 . 8 2005. 07 . 20-01
POWER ON Power On
MUTE PIC ON
HCT ON
DURATION 8
MODE 6 : default value : 10001100
Bit 0 - Bit 1: Power ON (Power on status 00:ON, 01:standby, 10 last status)
Bit 2 : MUTE PIC (Mute picture when changing channel; 1:ON)
Bit 3 : HCT (High Contrast for OSD; 1:ON)
Bit 4,5,6,7 : DURATION (mute time when changing channel; default 8)
MODE 7
U0C300C 1 . 8 2005. 07 . 20-01
16:9TUBE OFF
XRAY V 1.9V
XRAY T 750ms
4:3 OSVE ON
DOLBY OFF
MODE 7 : default value : 01110010
Bit 0 : No use
Bit 1 - Bit 2: X-RAY V (Detection voltage for X-ray protection; 01:1.9V)
Bit 3 - Bit 4: X-RAY T (Detect. time for X-ray protection; 10: 750ms)
Bit 5 : No use
Bit 6 : 4:3 OSVE (selection of vertical over scan; 1:ON)
Bit 7 : DOLBY (selection of DOLBY; 1:ON)
MODE 8
U0C300C 1 . 8 2005. 07 . 20-01
VMA ST off
SVM ST 50ns
SPR ST 0/-3/-3
MODE 8 : default value : 00101000
Bit 0-Bit 1 : VMA (Amplitude of SVM output ; 00 : ST OFF)
Bit 2,3,4 : SVM (Delay of RGB to SVM output; 010 : ST 50ns)
Bit 5,6,7 : SPR (Parabola on SVM output; 001 : 0/-3/-3)
MODE 9
U0C300C 1 . 8 2005. 07 . 20-01
VMA WK off
SVM WK 50ns
SPR WK -6/-3/-0
MODE 9 : default value : 11001000
Bit 0-Bit 1 : VMA (WEAK status 00: OFF)
Bit 2,3,4 : SVM (WEAK status 010: 50ns)
Bit 5,6,7 : SPR (WEAK status 110: -6/-3/-0)
MODE 10
U0C300C 1 . 8 2005. 07 . 20-01
SVMA 600mVpp
CRA0 8%
TXTLV 0
COFF False
No use OFF
MODE 10 : default value : 00100000
Bit 0 : SVMA (SVM output signal ; 0 : 600mVpp)
Bit 1 : CRA0 ( adjusted to 8% - Bit 1 = 0)
Bit 2,3 : TXTLV (Scavem on TXT ampl.; 10: 1000mVpp)
Bit 4 : COFF ( adjusted to False - Bit 4= 0)
Bit 5,6,7 : No use
