ETC009 - ETC010
First issue 01 / 06
5.5 - Mode adjustment
Press key "9" to enter Mode adjustment.
Item
Bit 0
Bit 7
Data
MODE 1 010110100
00001110
MODE 2 10011111 (10011011 for TDA12070/12072 without L standard)
MODE 3 00000000
MODE 4 11111101
MODE 5 01000000
MODE 6 10001100
MODE 7 01110010
MODE 8 00000000
MODE 9 11001000
MODE 10 00110000
U0C300C 1 . 8 2005. 07 . 20-01
MODE 1 00110101
MODE 2 10010111
MODE 3 00000000
MODE 4 11111101
MODE 5 11000000
MODE 6 10001100
MODE 7 01110010
MODE 8 00101000
MODE 9 11001000
MODE10 00100000
Check the bytes values. They indicate the configuration of the chassis and are given for information only.
The default values are indicated in the follow table.
- Choose the item MODE 1 ,MODE 2 ... by pressing up/down key.
- Access to the selected MODE adjustments by pressing ”Left” or ”Right” key
MODE 1
U0C300C 1 . 8 2005. 07 . 20-01
D-MODE
Direct Key enter disabled
AV OUT Always TV
NO SIG. Mute when no signal
MUTE AV0
Don't mute AV-Out
NI ADISP OFF
SEARCH Fast
TUNER CP OFF
TXT FIN OFF
MODE1 : default value : 10110100
Bit 0 : D-MODE (Direct enter D-mode (Service mode) with ”OK” key
0:enable 1:disable)
Bit 1 : AV OUT (0: Always TV - 1: Follow source)
Bit 2 : No Signal (0: Demute when no signal - 1 mute when no signal)
Bit 3 : MUTE AV0 (Mute AV-out)
Bit 4 :
NI ADISP (1: Nicam auto detection OSD display enable)
Bit 5 : SEARCH (Auto search speed setting)
Bit 6 : TUNER CP (CP bit selection of tuner)
Bit 7 : TXTFIN (TXT fine tuning selection)
MODE 2
U0C300C 1 . 8 2005. 07 . 20-01
SOUND DK ON
SOUND BG ON
SOUND M OFF
DEF SND
BG
MAX PROG 100 Prog
AUTO SND
Request auto sound
MODE 2 : default value : 10011111
Bit 0 : SOUND DK (depends on requirement)
Bit 1 : SOUND BG (depends on requirement)
Bit 2 : SOUND L (or I)* (depends on requirement)
Bit 3 : SOUND M (or I)* (depends on requirement)
Bit 4 - Bit5 :
DEF SOUND (00: DK; 01: BG; 10: I; 11:M)
Bit 6 : MAX PROG. (0: 100, 1:200 (no used))
Bit 7 : AUTO SND (Request auto sound detect when auto searching
(0: Don’t request 1: request auto sound)
* according models
MODE 3
U0C300C 1 . 8 2005. 07 . 20-01
DBB/DVB DVB
AVL OFF
Tilt OFF
COMBFILT OFF
VM OFF
Secam OFF
SuperRec OFF
MODE 3 : default value : 00000000
Bit 0-Bit 1 : DBB/DVB (Woofer 00:DVB; 01:DB; 10: Woofer, 11:OFF)
Bit 2 : AVL (0: OFF)
Bit 3 : Tilt (0: OFF)
Bit 4 : COMB (Comb filter : 0: OFF)
Bit 5 : VM (0:OFF)
Bit 6 : SECAM (0:OFF)
Bit 7 : SUPERREC (0:OFF)
MODE 4
U0C300C 1 . 8 2005. 07 . 20-01
IF Freq 38.9MHz
AV1 ON
AV2 ON
AV3 ON
S-VIDEO1 ON
S-VIDEO2 ON
RGB ON
MODE 4 : default value : 11111101
Bit 0-Bit 1 : IF FREQ (00:45.75MHz; 01:38.9MHz; 10: 38MHz)
Bit 2 : AV1 (1:ON) (depends on requirement)
Bit 3 : AV2 (1: ON) (depends on requirement)
Bit 4 : AV3 (1: ON) (depends on requirement)
Bit 5 : S-VIDEO1 (1: ON) (depends on requirement)
Bit 6 : S-VIDEO2 (1: ON) (depends on requirement)
Bit 7 : RGB (1: ON) (depends on requirement)
To Next Page
