THOMSON ETC009 - Page 6

ETC009 - ETC010
First issue 01 / 06
IV - FACTORY ALIGNMENT VALUES
V - SERVICE MODE VALUES
5.1 Analog control adjustment
Press key "5" to enter analog adjustment.
KEY 1 KEY 2 KEY 3 KEY 4
Item Data Item Data Item Data Item
Data
RED 32 5VPOS 32 5HSH 42 VOL 01
30
GRN 32 5VAM 23 5PAR 33 VOL 10
104
WPR 32 5VSL 28 5BOW 29 VOL 90
170
188( ETC009 5W)
194(ETC010 6W)
WPB 32 5VL 30 5EWW 39 VOL 100
176(ETC010,10W)
31(ETC009)
21( for 14”15”)
WPG 32 5VSC *
*
31 5EWP 34 CNTC
31(ETC010)
REDC 32 5SCL 31 5UCR 46 BRTC
30
GRNC 32 RF AGC 22 5LCR 43 COLC
23
WPRC 32 5EWT 26 TNTC
35
WPGC 32 5WBR 7 COLP
3
WPBC 32
AGCL 22
5WBF 7 COLS
23
REDSECAM 32 SHPTV
32
GRNSECAM 32
No adjustable
KEY 5
Data
Item
ETC009 ETC010
CNTX Max. Contrast value 63
13
63
CNTN Min. Contrast value
BRTX Max. Brightness value 63 63
BRTN Min. Brightness value 15 15
COLX Max. Color value 50 50
00
00
00
COLN Min. Color value
TNTX Max. Tint value 63 63
TNTN Min. Tint value
SHPX Max. Sharpness value 63 63
SHPN Min. Sharpness value
5.2 - Picture item adjustment
Press key "6" to enter analog adjustment.
Item
Data
ETC009 ETC010
CPFK PAL Peaking value
NTS peaking frequency & value
32 32
CFPEK PAL PAL peaking frequency & value 3.5M 143NS 3.5M 143NS
CFPEK NTS 3.1M 160NS 3.1M 160NS
CFPEK YUV YUV peaking frequency & value 4.0M 125NS 4.0M 125NS
IFPL IF Offset 32 32
BBTC Base-band tint control (phase U,V signal) 32 32
PGR Original value of R 55 55
PGG Original value of G 55 55
PGB Original value of B 55 55
0
ON
VAM (depends on tube) 3 ( depends on tube)
VG2BRI Brightness of V line when adjust G2 20 20
3 4
HDOL RGB drive gain.
5.3 - OSD Position adjustment
` Press key "7" to enter analog adjustment.
Item
Data
OSD BRI OSD brightness 8
CC BRI Teletext brightness 5
5CCD H Position for Teletext 11
5CCD V Position for Teletext 40
5OSD H OSD H position 9
5OSD V OSD V position 32
5MENU V Menu V. position 55
10
5MENU H Menu H. position
