E. Typical Interior Component Layout Drawing
3 Pole Model Shown (2 Pole Model has 3
rd
Pole (Phase C) Removed)
NEUTRAL
UTILITY
SUPPLY
A B C
GEN SUPPLY
(TOP LUGS)
TSC 9
CONTROLLER
A B C
GROUND
LOAD
(BOTTOM LUGS)
CUSTOMER
CONTROL
CONNECTIONS:
•
GEN START
•
LOAD SHED
•
ALARM
•REMOTE TEST
TRANSFER
MECHANISM
ENCLOSURE
MOUNTING
HOLES (TYP 4)
