9087A – 198
th
Street, Langley, BC Canada V1M 3B1 Telephone (604) 888-0110
Telefax (604) 888-3381 E-Mail: info@thomsontechnology.com www.thomsontechnology.com
TS 910
AUTOMATIC TRANSFER SWITCHES
OWNERS MANUAL
INSTALLATION, OPERATING &
SERVICE
PM140 Rev 0 12/02/09

Table of Contents

Questions and Answers

  • E
    Emily PetersJul 31, 2025
    What to do if THOMSON TS 910 will not re-transfer to utility source upon restoration?
    • D
      Denise GrahamJul 31, 2025
      Several factors can prevent the THOMSON Switch from re-transferring to the utility source after power is restored. Here's what to check: * Ensure the TSC 9 Isolation plug is properly reconnected. * Deactivate any active test modes. * Confirm the utility voltage is above 80% of its rated value. * Inspect and secure any loose control connections. * Replace the utility solenoid coil if it's defective. * Verify the correct voltage configuration jumper setting on TSC 9. * Replace the TSC 9 controller if it's defective. * Address any "Transfer Fail" alarms on TSC 9 before resetting. * Wait for the in-phase condition to be detected before transfer.
  • M
    melissachandlerAug 7, 2025
    Why THOMSON TS 910 transfers to generator source without a power failure on the utility source?
    • K
      Kristin SimmonsAug 7, 2025
      If your THOMSON Switch transfers to the generator source when there is no power failure, it might be due to these reasons: * A TEST or EXERCISE mode might be activated, so deactivate it. * The utility supply voltage might be less than 70% on one or both phases of nominal voltage, so ensure the utility supply voltage is at least 70% on both phases. * The TSC 9 might have the incorrect voltage configuration jumper setting for system voltage, so set the correct voltage configuration jumper setting on TSC 9. * The TSC 9 controller might be defective, so replace the defective TSC 9 controller.
  • G
    Gregory TurnerAug 15, 2025
    What to do if THOMSON Switch will not transfer to generator source upon failure of utility source?
    • M
      Misty BlairAug 16, 2025
      If your THOMSON Switch fails to transfer to the generator source when the utility source fails, consider these potential causes: * Ensure the TSC 9 Isolation plug is securely reconnected. * Verify that the generator set is producing sufficient voltage and frequency and that the output circuit breaker is closed. * Confirm that TSC 9 has the correct voltage configuration jumper setting for your system's voltage. * Check the TSC 9 timer setting and allow the warm-up time delay to complete. * Inspect and secure any loose control connections. * Replace the generator solenoid if it's defective. * Replace the TSC 9 controller if it's defective. * Address any "Transfer Fail" alarms on TSC 9 before resetting. * Wait for the in-phase condition to be detected before transferring.
  • A
    ashley50Aug 23, 2025
    How to troubleshoot if generator does not start up or stop when it should in THOMSON TS 910?
    • B
      Billy EllisAug 23, 2025
      If the generator in your THOMSON Switch doesn't start or stop as expected, or if there's no time delay when there should be, check the following: * Ensure the remote engine control panel is set to automatic mode. * Verify that the engine start wiring is connected to the correct terminals on the TSC 9 controller. * Check and secure the engine start wiring at both the transfer switch and the engine control panel. * Verify the time delay setting of the TSC 9 controller and adjust if necessary.

Summary

Equipment Storage

Notes to Installer

3.3. Check Line Voltage;Amperage

Instructions to verify the transfer switch voltage and amperage match site requirements.

3.4. Installation Requirements

Details requirements for permits, sizing, location, and power cabling.

3.4.8. Withstand;Interrupting Current Ratings

Details the withstand and interrupting current ratings for TS 910 models.

General Description

4.3. Typical Commissioning Procedures

Provides general information on typical commissioning procedures.

General Theory of Operation

5.1. Automatic Sequence of Operation

Details the step-by-step sequence of automatic operation.

Over Current Protection

General Notes on Servicing Transfer Switch Mechanism

Transfer Switch Mechanism Operation

8.1. Automatic Operation

Describes the automatic operation of the transfer switch.

8.2. Manual Operation

Details how to operate the transfer switch manually.

Recommended Maintenance

Enclosure Dimensions;Cable Terminals

Requirements for Upstream Circuit Protective Devices

17.2. 100 A Transfer Switch Upstream Circuit Protective Devices

Lists upstream circuit breakers suitable for 100A transfer switches.

17.3. 200 A Transfer Switch Upstream Circuit Protective Devices

Lists upstream circuit breakers suitable for 200A transfer switches.

17.4. 400 A Transfer Switch Upstream Circuit Protective Devices

Lists upstream circuit breakers suitable for 400A transfer switches.

TSC 9 Transfer Switch Controller

18.2. Electrostatic Discharge Precautions

Provides precautions for handling static-sensitive parts of the TSC 9 controller.

18.5. TSC 9 Faceplate Lights and Pushbutton Operation

Describes the operation of TSC 9 controller lights and pushbuttons.

18.6.1.2. Configuration Jumpers

Explains the use of configuration jumpers on the PCB for system parameters.

TSC 9 Operating Instructions

18.7.1. Automatic Sequence of Operation

Refers to Section 5 for information on automatic operation.

18.7.2. TSC 9 Controller Operation Pushbuttons

Explains how to use the TEST, EXERCISE, and other pushbuttons.

TSC 9 Operating Mode Descriptions

18.8.1. Transfer Switch Fail Alarm Logic

Details the alarm logic for transfer switch failures.

18.8.1.4. Fail to Transfer (In-Phase Detection)

Explains the alarm condition for failure to transfer due to in-phase detection.

Test Modes

18.9.1. Utility Power Fail Simulation (Load Test)

Details how to simulate a utility power failure for testing.

18.9.2. Generator Exercise Test

Explains the automatic generator exercise mode and its configuration.

Timer Bypass

TSC 9 Voltage Sensing

TSC 9 Generator Frequency Sensing

TSC 9 Configuration Instructions

Load Shed

TS 910 Schematic Diagram

Troubleshooting

Replacement Parts

Appendix A - Typical Automatic Transfer Switch Commissioning Procedures

a) Pre-Energization Checks

Lists checks to perform before energizing the transfer switch.

b) Equipment Energization

Details the procedure for energizing the equipment and verifying operation.
