17.2. 100A TRANSFER SWITCH UPSTREAM CIRCUIT PROTECTIVE DEVICES
100A transfer switches are suitable for use on circuits capable of delivering 10,000 Amps
(RMS symmetrical), 240V when protected by the following upstream circuit breakers:
MANUFACTURER MANF CATALOG NUMBER RATINGS
Eaton/Cutler Hammer FCL, FB, QCHW, GB, GHB, GC,
GHC, GD, EHD
100A, 240V
Eaton/Cutler Hammer FDB, FD,HFD, FDC, CA, CAH 150A, 240V
Square D FI/FC/FA/FH 100A, 240V
Square D QOM1, QOM1-VH 125A, 240V
Square D QOM2 QOM2-VH 225A, 240V
Square D Q2, Q2-H 175A, 240V
Square D QB, QD, QG, GJ 250A, 240V
Siemens CED6, D2, ED4, ED6, HED4,
HED6, QP(Q2125),
QPH(QH2125H)
125A, 240V
Siemens QJ2, QJH2, 150A, 240V
GE THQB, THQB, THHQB, THHQC 100A, 240V
GE THHQL, TQDL, THQDL 125A, 240V
GE TQD, THQD, THED 150A, 240V
