TS 910 TRANSFER SWITCH
PM140 REV 0 12/02/09 28 Thomson Technology
18.4. TSC 9 FACEPLATE
The TSC 9 Controller faceplate is shown as in FIGURE 1
Gen Supply Available LED light
Diagnostic Active LED light
System OK LED Light
Wait for Transfer LED Light
USB Factory Programming Port
Utility Supply Available LED light
Load Shed LED light
Load on Utility LED light
Load on Gen LED light
Gen Exercise Mode Pushbutton & LED light
Test Mode Pushbutton & LED light
Gen Start LED light
Alarm Active LED light
ATS Alarm Active LED light
System OK LED Light
