Page #13 background imageLoading...
Page #13 background image
TS 910 TRANSFER SWITCH
PM140 REV 0 12/02/09 7 Thomson Technology
4.2. TS 910 OPTIONAL ACCESSORIES
The following optional accessories may be ordered as field installable kits.
Model Code Description
TS910-HTR
Enclosure Heater, 120VAC Fused, supplied from ATS
Load Bus
TS910-SPD1PH
Surge Protective Device, Class 1, 120/240V connected
to Load Bus
TS910-KWLS1PH2
kW Load Shed Control output contact, Single Stage, 0-
200A Current Transformers connected to ATS Load Bus
TS910-KWLS1PH4
kW Load Shed Control output contact, Single Stage, 0-
400A Current Transformers connected to ATS Load Bus
TS910-WMS
Wireless Remote Alarm Messaging Module
TS910-N3R100A
TS910-N3R100B
TS910-N3R200A
TS910-N3R200B
TS910-N3R400A
TS910-N3R400B
NEMA 3R Door, External Door Mountable to NEMA 1
ATS Enclosure (Specify matching ATS model number)
Additional information on TS 910 optional accessories can be obtained from our
Website (www.thomsontechnology.com ).
4.3. TYPICAL COMMISSIONING PROCEDURES
CAUTION:
Commissioning procedures must be performed by qualified
personnel only.
Note: The TYPICAL AUTOMATIC TRANSFER SWITCH COMMISSIONING
PROCEDURES MODEL SERIES TS 910 (attached as Appendix A”) is provided for
general information only pertaining to typical site installations and applications. Contact
Thomson Technology for further information as may be required.
