TS 910 TRANSFER SWITCH
PM140 REV 0 12/02/09 30 Thomson Technology
18.6. TSC 9 PRINTED CIRCUIT BOARD
FIGURE 2
Configuration
Jumpers
J4 – Controller
Isolation Wiring Plug
Current Transformer
Plugs
(KW Load Shed Option)
Expansion Port
(Future)
Customer Interface
Control Terminal Block
USB Factory
Programming
Port
J6 –RS 232
Interface Plug
(Wi-Fi Option)
KW Adjustment Switches
(KW Load Shed Option)
