TS 910 TRANSFER SWITCH
PM140 REV 0 12/02/09 16 Thomson Technology
10. FRONT INTERIOR VIEW (2 POLE 100A STANDARD ATS)
NEUTRAL
UTILITY SUPPLY
L1 L2
GEN SUPPLY
(TOP LUGS)
TSC 9
CONTROLLER
L1 L2
GROUND
LOAD
(BOTTOM LUGS)
CUSTOMER
CONTROL
CONNECTIONS:
•GEN START
•LOAD SHED
•ALARM
•
REMOTE TEST
TRANSFER
MECHANISM
ENCLOSURE
MOUNTING
HOLES (TYP
4)
