TS 910 TRANSFER SWITCH
PM140 REV 0 12/02/09 22 Thomson Technology
16. ENCLOSURE DIMENSIONS/CABLE TERMINALS
DIMENSIONS TERMINAL RATING
MODEL TYPE AMPERAGE
HEIGHT
INCHES
WIDTH
INCHES
DEPTH
INCHES
SHIPPING
WEIGHT
LBS
QTY
PER
PHASE
RANGE
TS912A0100A
STD ATS 100A 16 1/8" 18 7/8" 8 1/4" 20 lbs 1 #14 - 1/0
TS912A0100B
SE ATS 100A 27 1/8" 18 7/8" 8 1/4" 30 lbs 1 #14 - 1/0
TS912A0200A
STD ATS 200A 27 1/8" 18 7/8" 8 1/4" 30 lbs 1 #6 - 250mcm
TS912A0200B
SE ATS 200A 31 1/8" 18 7/8" 8 1/4" 35 lbs 1 #6 - 250mcm
TS912A0400A
STD ATS 400A 45 1/8" 24 7/8" 11" 70 lbs 2 #6 - 250mcm
TS912A0400B
SE ATS 400A 45 1/8" 24 7/8" 11" 80 lbs 2 #6 - 250mcm
17. REQUIREMENTS FOR UPSTREAM CIRCUIT PROTECTIVE DEVICES
17.1. TRANSFER SWITCH WITHSTAND CURRENT RATINGS
WITHSTAND CURRENT RATING AMPS (RMS)
With Upstream
Circuit Breaker
Protection
With Upstream Fuse
Protection
MODEL
MAX.
VOLTAGE
RATED
CURRENT
(A)
@240V
@ Up to
240V Fuse Type
TS912A0100A
240 100 10,000 100,000 T, J
TS912A0200A
240 200 10,000 100,000 T, J
TS912A0400A
240 400 25,000 100,000 T, J
Fuse ratings shown are maximum allowable to permit use of the transfer switch in application
with available fault current not exceeding that shown. Consideration must be given to fuse
sizing when fuses also provide overload protection.
