Chapter 1: Connections and Setup
18
X
OFF
FLASH
ON
X X X
NO Ether carrier present
Ether TX/RX traffic
Ether carrier present, no traffic
OFF
FLASH
ON
X X X X
No 802.11g installed or wireless is disabled from
WEB
Wireless TX/RX traffic
802.11g is functional
FLASH FLASH FLASH FLASH FLASH
SW Download
Operation
From Right to Left
A software download and while updating the FLASH
memory
X X X Wink X
No service
Operation
Three seconds ON followed by a flash OFF
NACO =OFF
BPI unauthorize (when BPI is ON)
Press Button
On Internet ON-OFF switch on.
Internet
On/Off
Button
Off Internet ON-OFF switch off.
