1.2. Components of the Printer
| Front View
Serial No.
1 Output Bin Output Bin
2 Control Panel Control Panel
3 Output Tray Output Tray
4 Automatic Feed Guide Manual Feed Guide
5 Paper Stop Automatic Feed Guide
6 Feeder Tray Paper Stop
7 Automatic Feeder Tray Manual Feeder Tray
8 Automatic Feeder Tray
9 Feeder Tray
| Rear View
Serial No.
1 Network Interface Network Interface
2 USB Interface USB Interface
3 Power Switch Power Switch
4 Power Interface Power Interface
Note:
The rear view of the printer may vary dependi
ng on the models and functions.
TH-2600TH-2500
TH-2600TH-2500
