Oven Knob Installation
1. Check the sheet for the quantity of each knobs
Model #
Big Oven Thermostat
Knob
Griddle/Small Oven
Thermostat Knob
Surface Valve Knob
LRG3001U
1
0
5
Model #
Big Oven Thermostat
Knob
Griddle/Small Oven
Thermostat Knob
Surface Valve Knob
LRG3601U
1
0
6
LRG4801U 1 2 6
LRG4807U 1 2 6
*For any parts damage or missing, please contact 877-288-809,
or send email to service@thorgroup.us
2. Find the right knob for each shaft on the range. Push the
knob in to fully attach the shaft and make sure there’s no
friction between knobs and bezels.
****In correct Knob Installation will cause the damage of the oven
thermostat / burner valve****
(Incorrect knob caused broken thermostat shaft)
LRG2401U
1
0
4
