INSTALLATION INSTRUCTIONS
NAMES OF THE PARTS
SPECIFICATIONS - MODEL #TRF24U
1. Upper drawer & handle
2. Cabinet
3. Lower drawer & handle
4. Exhaust grill
5. Compressor & power board (on the rear)
Product Description
Model No.
Unit Dimensions
(inches)
Net Weight (lbs)
TRF24U
Width
23.6”
34 41/64” 880mm
635mm
610mm
25“
24”
34.25”
27.36”
(with handle)
Height Depth
Built-In FRIDGE
119 lbs
Install the outdoor drawer refrigerator:
Height of housing
Depth of housing
Width of housing
Your product has been designed built-in for free standing installation.
Cutout Dimensions
Dimensions of the recess
Attention: the ventilator shuold not be covered, or it will cause unpredictable breakdown: the fan and
the return-airway shouldn not be covered or it will cause the temperature of the frige to not meet its set
tempreture, and the temp of the cabinet will be uneven.
