THORLABS MC2000 - Figure 3: Circuit Board Layout with 110;220 VAC Switch

Optical Chopper System
18488-D02 Rev G, September 24, 2012 Page 21 www.thorlabs.com
Front
Back
Figure 3: Circuit Board Layout with 110/220 VAC Switch
Line Voltage Selection Switch
Set the switch to the appropriate voltage.
