Optical Chopper System
18488-D02 Rev G, September 24, 2012 Page 24 www.thorlabs.com
Communications
Communications Port USB
Protocol USB (RS232 Emulated)
Baud Rate 115,200 (fixed)
Data Bits 8
Stop Bits 1
Parity None
Handshaking None
Optical Head Specifications
Chopping Blade Diameter Ø4.0" (Ø101.6 mm)
Chopping Blade Thickness 0.010" (0.254 mm)
Mounting Base 1/4"-20 (or M8) Clearance Slots Spaced 3.0"
(Compatible with Thorlabs Breadboards)
Mounting Hole 1/4"-20 with 1/4" Max Screw Depth
Blade Specifications
Chopping Blade Slots
(4)
MC1F2 2
MC1F10 (Default Blade) 10
MC1F15 15
MC1F30 30
MC1F60 60
MC2F57 7 Outer, 5 Inner
Slot Angle
MC1F2
180°
MC1F10 (Default Blade)
36°
MC1F15
24°
MC1F30
12°
MC1F60
6°
MC2F57
51.4° Outer, 72° Inner
