Si Amplified Fixed Gain Detector
Page 8 TTN134700-D02
4
Measured from the active area to the start of the threads on the housing body. The detector
active area surface is flush with the front of the housing body.
5
Although the power supply is rated for 6 W, the detector’s actual usage is <5 W over the full
operating range.
General
On/Off Switch
Slide
Output
BNC (DC Coupled)
Package Size
2.79" x 1.96" x 0.89"
(70.9 mm x 49.8 mm x 22.5 mm)
PD Surface Depth
4
0.09" (2.2 mm)
Weight, Detector Only
0.10 kg
Accessories
SM1T1 Coupler
SM1RR Retainer Ring
Operating Temp
10 to 50 °C
Storage Temp
-25 to 70 °C
AC Power Supply
AC - DC Converter
Input Power
5
6 W
100 V / 120 V / 230 V, 50 - 60 Hz
