Si Amplified Fixed Gain Detector Chapter 4: Operation
Rev B, January 3, 2019 Page 5
Indium Gallium Arsenide
(InGaAs)
Extended Range: Indium
Gallium Arsenide (InGaAs)
4.4. Bandwidth and Response
For the PDA detectors, the gain of the detector is dependent on the feedback
element (R
f
). The bandwidth of the detector can be calculated using the following:
Where GBP is the amplifier gain bandwidth product and C
D
is the sum of the
photodiode junction capacitance and the amplifier capacitance.
4.5. Terminating Resistance
The maximum output of the PDA10A2 is 10 volts for high impedance loads (i.e.
R
Load
> 5 kΩ) and 5 V for 50 Ω loads. Adjust the gain so that the measured signal
level out of the PDA10A2 is below 10 V (5 V with a 50 Ω load) to avoid saturation.
For low terminating resistors, <5 kΩ or 1% error, an additional factor needs to be
considered. The output of the PDA includes a 50 Ω series resistor (R
s
). The output
load creates a voltage divider with the 50 Ω series resistor as follows:
Note that we already include the scale factor in our specification for the gain at
50 Ω. Refer to the table in Chapter 6 for additional performance specifications.
Approximate values; actual wavelength values will vary.
