© 2019 Thorlabs
4 Appendix
18
PM101
PM101A
PM101R
PM101U
Remote Interfaces
Remote Interface Type 1
USB 2.0
Connector
Mini-B USB
Measurement Speed
Up to 1000/s
Remote Interface Type 2
RS232
RS232
Connector
DA-15 Pin 7/8
NA
DE-9 Pin 2/3
NA
Baud Rate
9600 - 230400
Bit/s
Default: 115200
Bit/s
NA
9600 - 230400
Bit/s
Default: 115200
Bit/s
NA
Settings
N1S
NA
N1S
NA
Measurement Speed
Up to 200/s
NA
Up to 200/s
NA
Analog Output, Configurable
Connector
DA-15 Pin 5
SMA
NA
NA
Signal
Gain Signal Con-
figurable
Gain Signal Con-
figurable
NA
NA
Voltage Range
0 to 2.5 V
0 to 2.5 V
NA
NA
Accuracy
±1%
±1%
NA
NA
Bandwidth
1 kHz
1 kHz
NA
NA
Analog Input, Not Corrected
Connector
DA-15 Pin 4
NA
NA
NA
Signal
Amplified Input
Signal - Not Cor-
rected
NA
NA
NA
Voltage Range
0 to 2.5 V
NA
NA
NA
Accuracy
±3%
NA
NA
NA
Bandwidth
up to 100 kHz,
Dependent on
Sensor and Set-
tings
NA
NA
NA
Auxiliary Temperature Control
Connector
DA-15 Pin 14
NA
NA
NA
Supported Temperature Sensor
Thermistor NTC
0.1 - 100 kΩ,
B-Value:
1000 - 9999 K
NA
NA
NA
Temperature Measurement
Range
-40 °C to +200 °C
(NTC dependent)
NA
NA
NA
Digital Control Pins I/O
Connector
DA-15 Pins 2/3
NA
NA
NA
Function
2 x GPIO
NA
NA
NA
Power Management
DC Input 1 / Connector
+5 VDC to +36
VDC /
DA-15
NA
NA
NA
DC Input 2 / Connector
5 V / USB
Power Consumption
1 W
Display
Display Type
None; External PC - Windows Application or Driver Set
