© 2019 Thorlabs
1 General Information
4
1.3 Requirements
Hardware Requirements
PM101: Please provide an appropriate cable to be attached to the DA-15 connector.
PM101A: Please provide an appropriate cable to connect to the SMA port.
Software Requirements
All models of the PM101x can be run with the Thorlabs' OPM software. Please see the require-
ments for the OPM on the website.
Sensor Requirements
Thorlabs C-Series Sensors
The PM101x supports all Thorlabs C-Series photodiode and thermal sensors. The C-Series
can be easily identified by the red connector-housing of the DE-9 connector, compared to older
versions of Thorlabs power sensors.
Please refer to the chapter Connecting a Power Sensor on how to use older Thorlabs
sensors or custom sensors.
6
