© 2019 Thorlabs3
PM101x
1.2 Ordering Codes and Accessories
PM101
Power Meter Interface with DA-15 Connector; USB, RS232, or UART Operation.
Digital or Analog Signal Output; Two Auxiliary I/O Ports; NTC Input; USB Interface
for Control and Power Supply.
PM101A
Power Meter Interface with SMA Connector for Analog Output; USB Interface for
Control and Power Supply.
PM101R
Power Meter Interface with DE-9 Connector; RS232 Operation for Control and
Read Out; USB Interface for Control and Power Supply.
PM101U
Power Meter Interface with USB Connector and USB Operation for Control, Read
Out, and Power Supply.
Included Accessories:
The PM101x Power Meters include certain cables. Further cables are recommended in Op-
tional Accessories .
PM101: DA-15 Connector and Connector Housing
USB Cable, Type A to Mini B, with locking screw, 1.5m
PM101A: USB Cable, Type A to Mini B, with locking screw, 1.5m
PM101R: RS232 cable, DE-9 male to DE-9 female, 1.8m
USB Cable, Type A to Mini B, with locking screw, 1.5m
PM101U: USB Cable, Type A to Mini B, with locking screw, 1.5m
Optional Accessories:
To run the PM101x power meter, additional cables or mounting devices may be required.
Cables
· PM101A: SMA cable: please provide a cable with a SMA connector with your PM101A.
Thorlabs offers a variety of SMA connector cables.
· PM101: Cable to attach to the provided DA-15 connector housing.
Mounting
· Horizontal Mounting Clamp (ECM225) to mount the PM101x onto a post.
· Vertical Mounting Clamp (ECM100) to mount the narrow side of the PM101x onto a post.
· Double Sided Horizontal Mounting Clamp (EPS225) to securely mount two devices on top of
each other.
Please visit our homepage http://www.thorlabs.com for various accessories like power and
thermal sensors, fiber adapters, posts and post-holders.
3
