Logging Control: Three modes can be set: manual start/stop,
timed logging or logging of a number of samples.
Measurement Interval: The logging interval (time between two
measurements) can be set from 1 to 10000 seconds.
Averaging: When averaging is unchecked, a single measured
value per selected measurement interval will be logged. By
checking this box, all values that are measured each second will
be averaged over the period of the selected measurement interval
and only this average value will be logged. That means per
measurement interval for both options one single value will be
logged only.
Time Axis Scale: 3 selections are available: time in seconds, time
in hours:minutes:seconds and time stamp (date an time). The
complete time stamp (date and time) will be displayed only in the
Table tab.
Start / Stop Logging This is a toggle button to start / stop logging
process.
Results In this pane logging statistics are displayed.
In the tab Table all logged data vs. time are
displayed numerically.
Column description:
Time: format as selected for "Time Axis Scale"
Results: The values from all sensors are
displayed. If an external sensor is not enabled or
not present, the values show "--.---"
Remarks: empty if no error occurred, otherwise an
error message will be displayed
