step 3: attach the door stoppers to the top panel
3.1. Using the pilot holes as a guide, attach the door stoppers (H10) to the top panel (A) with four 10 mm screws (H11).
(H10) x 2
door stopper
Pilot hole
H10
A
A
H11
NOTE: DO NOT use power tools.
9
(H11) x 4
M3 x 10 mm screw
