step 4: fasten the top reinforcement
4.1. Using the pilot holes as a guide, orient and fasten the top reinforcement (F) to the top panel (A) with six 38 mm screws (H8).
(H8) x 6
M4 x 38 mm screw
A
F
H8
NOTE: DO NOT use power tools.
H8
H8
H8
H8
H8
10
The countersunk holes face upward
