REQUIRED TOOLS
• Metric Allen Key Set
• Metric Open-Ended Wrench Set
• Large Adjustable Crescent Wrench
PACKAGING REMOVAL:
Carefully remove all packaging materials that wrap the equipment. If parts are missing see Support
& Service
DO NOT USE A KNIFE OR BOX CUTTER AS YOU MAY DAMAGE THE EQUIPMENT.
At this time remove any sub-components from the pallet and set aside for later assembly. Once all packaging
has been removed, lay all parts out in a clean open area to prepare for assembly. Should any component not
be present or if you have any operational questions, please refer to SUPPORT & SERVICE
After assembly, a complete visual inspection, and test of the features and functions of the
assembled unit must be made prior to use.
IN THE BOX
H
F
G
A
B
E
D
C
Fig. 2
Shipped Parts
ASSEMBLY
# PN Description
A 701-0541 THROWDOWN HIIT CONSOLE KIT
B 620-9075 MANUAL, ASSEMBLY, HIIT UBE
C 718-5630 Kit, Hardware, Assembly, Airfit UB
D 720-5102 Plate, Tread, Platform, Ergo
E 720-5175-XX Assy, Bench, Seat, Ergo
F 720-5192-XX Assy, Grip, Hand, Ergo
G 720-5207-XX ASSY, PLATFORM, ERGO
H 720-5306-XX ASSY, BASE, MAIN, UBE, THROWDOWN
