Thrustmaster T500RS User Manual

13/20
- Select your position (up, in the center or down) then tighten the screws using the 2.5mm Allen key
supplied (20).
Long run position Short run position
& High resistance (default) & Low resistance
Number of possible travel or resistance positions
- Long travel with resistance of around 10Kg (22lbs)
:
- Medium travel with resistance of around 8.5Kg (18.7lbs)
- Short travel with resistance of around 7Kg (15.4lbs)
Note
(and vice versa)
: the longer the travel the higher the pedal resistance

Thrustmaster T500RS Specifications

General

Type	Racing Wheel
Force Feedback	Yes
Compatibility	PC, PlayStation 3
Rotation Angle	1080 degrees
Pedal Adjustability	Yes
Motor	Industrial-class brushless motor
Connectivity	Wired
Wheel Diameter	30 cm
Shifters	Paddle shifters
Mounting	Table
Pedals	Included (T3PA)
Power Supply	External power adapter
