51100986 - A
13
WARNING
Always attach the hitch’s back-up safety strap
in the manner described above. It serves as
additional protection against losing the carrier
during operation. Do not use the Bicycle
Trailer if you cannot attach the hitch’s back-up
safety strap around your bicycle frame for any
reason. Failure to install the hitch’s back up
safety strap may lead to the Thule child carrier
becoming separated from the bicycle.
WARNING
The hitch arm load shall be no less than
0.1kg/0.22lb and no greater than 8kg/17.6lb.
This is checked by measuring the downward
load exerted by the end of the hitch arm
while the Thule child carrier is loaded with
passengers and cargo.
4.7.5 attachIng the caRRIeR to youR
BIcycle
A. Positionthecarrierontheleftsideofyourupright
bicyclewiththehitchballpointingtowardsthe
ezHitch™.(Seeimage1)
B. InsertthehitchballintothefrontoftheezHitch™and
slideitrearwardsuntilitstops.(Seeimage2)
C. InsertthesecuritypinintotheezHitch™fromthetop
sidepointingdown.
D. Pulltherubbertabdownovertheprotrudingendofthe
securitypintosecureitontheezHitch™.(Seeimage3)
E. Looptheback-upsafetystraparoundthebicycleframe
andhooktheclipontotheD-ring.(Seeimage4)
3
4
1
2
