Thule Top Deck 881 - Installation Steps; Attach Saddle Assemblies to Bars; Position Saddles

5015500_04
1
• Insert carriage
bolt through bracket and assembly base into wing knob.
Tighten loosely.
• Place assembly
onto bar as shown.
2
• Loosely attach other carriage bolt and knob as shown.
• Repeat
above
steps for all 4 saddle assemblies.
NOTE: Load bars must be at least 24" (610mm) apart for safe use.
3
• Position saddles for the approximate width of your boat.
