30
Throttle
UPPER ADJUSTMENT
Minor adjustments are generally made with the upper adjuster.
1. Pull the rubber dust cover back.
2. Loosen the upper lock nut on the throttle cable mechanism.
3. Turn the upper adjuster.
4. Tighten the lock nut. Return the dust coverto its normal position.
5. Aer adjustment, check for smooth rotationof the throttle grip from
fully closed to fullyopen in all steering positions.
Rubber Dust Cover
Upper Lock Nut
Upper Adjuster
