31
Throttle
SECOND ADJUSTMENT
e second adjuster is used for major freeplay adjustment, such as aer
replacing the throttle cables or removing the carburetor. It is also used if
you can not get the proper adjustment with the upper adjuster
1. Loosen the locking nut.
2. Turn the second adjuster.
3. Tighten the locking nut.
Maintenance tip: Recommend using a service spray WD40 or equivalent
inside the throttle cable housing and throttle
Locking Nut
Second Adjuster
