Thumpstar KXD - Lower Adjustment

34
Clutch System
LOWER ADJUSTMENT
e lower clutch cable adjuster is used if the upper clutch cable adjuster is
threaded out near its limit or the correct freeplay cannot be obtained.
1. Loosen the upper lock nut and turn the upper clutch cable adjuster all
the way in.
2. Tighten the upper lock nut and pull the dust cover back to its normal
position.
3. Hold the lower adjusting nut and loosen the lower lock nut at the lower
end of the cable.
4. Turn the lower adjusting nut to obtain the specied freeplay
5. Hold the lower adjusting nut and tighten the lower lock nut. Check the
adjustment.
6. Start the engine, pull the clutch lever in, and shi into gear. Make sure
the engine does not stall and the motorcycle does not creep. Gradually
release the clutch lever and open the throttle. Your motorcycle should
move smoothly and accelerate gradually.
Lower Adjusting Nut
Lower Lock Nut
TSX-C 125SW TSX-C 140bW
