Valve Clearance
6. If it is necessary to make an adjustment, loosen the adjusting screw
lock nut and turn the adjusting screw so there is a slight resistance
when the feeler gauge is inserted.
Aer completing the adjustment, tighten the adjusting screw lock nut
while holding the adjusting screw to prevent it from turning. Finally,
recheck the clearance to make sure that the adjustment has not been
disturbed.
7. Check that the mount rubbers in good condition. Install the mount
rubbers onto the cylinder head cover with the ‘‘UP’’ mark facing up.
Install a new gasket onto cylinder head cover. Install the cylinder head.
Install and tighten the cylinder head cover bolts.
Exhaust Valve
Intake Valve
Cam
Feeler Gauge
