Torque Settings
ITEM TORQUE
lbf. N.m kgf.m
FRAME
1 Steering stem nut 80 108 11.0
2 Fork bridge upper pinch bolts 16 22 2.2
3 Fork bridge lower pinch bolts 15 20 2.0
4 Handlebar upper holder bolts 16 22 2.0
5 Handlebar holder nuts 32 44 4.5
6 Front axle nut 65 88 9.0
7 Front axle pinch bolts 15 20 2.0
8 Rear axle nut 94 128 13.1
9 Chain adjuster lock nuts 20 27 2.8
10 Mid engine hanger bracket nut 47 64 6.5
11 Upper engine
hanger plate nuts
(engine side) 40 54 5.5
(frame side) 25 34 3.5
12 Shock
absorber
(upper) 32 44 4.5
(lower) 32 44 4.5
13 Swingarm pivot nut 65 88 9.0
14 Fork (fork damper) 25 34 3.5
(fork cap) 22 30 3.1
15 Rear shock arm
nuts
(swingarm side) 39 53 5.4
(shock link side) 39 53 5.4
16 Rear shock link nuts 39 53 5.4
17 Kickstarter arm bolt 28 38 3.9
