33
Changing the tail drive belt:
(1)Loosen and remove all the necessary
screws.
(2)After installing the new belt, make sure
the belt is rotated 90û counter clockwise.
(1)
(1)
(1)
(1)
(1)
(2)
Changing the flybar:
(1) Loosen or remove the M3x10 set screws.
(2) Unscrew the control paddles.
*Makesurethedistance from the rotor shaft to
both paddles are the same.
*Ifthe flybar is not perfectly straight or
smooth, it can be lightly sanded.
(2)
(1)
*After reinstalling the flybar and paddles, make
sure the paddles are level and flat.
