Let’s Get Started
Follow the steps below to boot up your device.
1. Connect the power adapter to the board assembly via DC in jack (connector 14).
2. Connect the board assembly to a computer via
 USB 3.1 Type-C connector (connector 12) if adb tool is needed.
 Micro USB connector (for UART debug) (connector 35) if debug function is needed.
3. Connect the board to a monitor via HDMI OUT connector (connector 13).
4. Set the DIP switch (connector 30).
 SW1301: Toggle all bits to OFF.
 SW1300:
 Bit 1~2: ON
 Bit 3 ~6: OFF
5. Press Power on button (connector 18) to boot up the device.
