OPERATING MANUAL DAF290 PRODUCT DESCRIPTION
ThyssenKrupp Aufzugswerke GmbH
2. Product Description
2.1 Description
1 Brake magnet 7 Housing
2 Brake release lever 8 Name plate
3 Forced ventilation 9 Traction sheave
4 Brake shoe 10 Disc on motor shaft
5 Terminal box 11 Rope fixing beam
6 Bearing bracket 12 Brake spring
Versions
The following versions can be supplied:
1. Groove profiles of the traction sheave
2. Machine base frame versions
3. Safety-relevant accessory parts
4. Additional encoder mounting
Special versions, see Appendix
5
4
11
10
8
3
6
1
7
9
2
12
Fig. 2.1
10
10-2012
Product has been
replaced
