OPERATING MANUAL DAF290 MACHINE SETUP
ThyssenKrupp Aufzugswerke GmbH
5.1 Commissioning
Before commissioning the machine, the following points should be checked
and carried out:
• Safety, auxiliary and installation tools removed from the danger zone
• Setup and alignment of machine, frame and rope departure checked
• Mounting of the machine and base frame checked
• Bolts tightened and secured to the prescribed torque (see 'Tightening
torques' table in the Appendix)
• Brake shoe stroke and setting checked
• Setting and function of the brake test switches checked
• Brake test carried out with one brake shoe in each case
• Function of handbrake release checked
• Rope protection cover fitted, function of safety shutdown device on
removing the traction sheave hood checked
• Power connections, earthing of motor, forced ventilation and brake magnet
connected, checked and secured
• Special add-on components (optional), 2nd pulse encoder function
checked
• Direction arrow (Up / Down) corresponding to the direction of travel glued
in a clearly visible position above the traction sheave to the brake vane
magnet
Product has been
