O
PERATING
M
ANUAL
DAF290
T
ECHNOLOGY
Th
y
ssenKrupp
Aufzugs
werk
e GmbH
3.
Technical Data
3.1
Dimensions
Permissible axle load of the motor shaft:
max. 60 kN
Braking torque:
max. 1600 Nm
Moment of inertia (mot. + tract. sh.) / (rope pulley)
7 kgm² / 1.5 kgm²
Fig. 3.1
12
10-2012
Product
has
been
replaced
11
13
Table of Contents
Default Chapter
5
Table of Contents
5
1 Safety
6
Symbols
6
Safety Instructions
7
2 Product Description
10
Description
10
Functional Description
11
3 Technical Data
12
Dimensions
12
Machine Base Frame - Optional
13
Lubrication
14
Encoder
14
4 Transportation and Storage
15
Commissioning
18
5 Machine Setup
19
Terminal Connecting Plans
19
6 Servicing
21
7 Maintenance
22
Replacing Brake Shoes
22
Checking and Setting Brake Shoe Stroke
23
Setting Braking Deceleration
24
Setting the Brake Test Switch
25
Traction Sheave Replacement
26
Replacing the Encoder
27
Checking for Escaping Grease/Oil
28
Position (Safety Gear)
29
8 Special Versions (SA) (Optional)
31
9 Appendix
32
Tightening Torques - Tightness Values
32
Accessory Parts
33
Changes
36
4
