OPERATING MANUAL 3. PRODUCT DESCRIPTION
ThyssenKrupp Aufzugswerke GmbH 20
Brake data:
Two different operating brake designs are used depending on the installation
data.
Note: the brake release magnets of the dual-circuit external shoe brake are
series-connected.
The tabular values are to be considered as total connection values for
series-connection.
Designation Unit Technical data
Manufacturer ThyssenKrupp Aufzugswerke
Type TW130
Brake torque Nm max. 2 x 125 max. 2 x 200
Brake torque setting possible
Design
Dual-circuit external shoe brake
with brake disk made of EN-GJL 250
Brake linings Asbestos-free
Brake disk diameter mm 265
Air gap mm 0,3
Setting of air gap adjustable
Electrical ventilation
1 magnetic clamp for each brake circuit
(2 series-connected magnetic clamps)
Rated load brake release
magnet
N 2500 5000
Operational voltage VDC 180 – overexcitation
90 - withstand voltage
Rated current A 1,5 1,7
Monitoring system Brake test switch
Manually-operated release With mounted-on brake release lever
Protection class magnetic
clamps
IP65
II 2 G EEx m II T5
IP65
II 2 G EEx m II T5
Length of connecting line m 1,3 1,5 1,7 1,5
Type test marking Without (not necessary)
