Value s

0.03 ... 9.99 step = 0.01

10.0 ... 99.9 step = 0.1

100 ... 200 step = 1

S< Logical block S<BLK1 OFF | ON

S< Trip relays S<TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10

S< Trip LEDs S<TR-L

START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9

| L10

Remote tripping

Remote tripping relays RemTrip-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10

Remote tripping LEDs RemTrip-L

START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9

| L10

Pilot wire diagnostic

BLOUT1 Diagnostic pulses period PulseBLOUT1 OFF | 100ms | 1s | 5s | 10s | 60s | 120s

BLIN1 Diagnostic pulses control time interval PulseBLIN1 OFF | 100ms | 1s | 5s | 10s | 60s | 120s

Not received pulses at BLIN signalling relays PulseBLIN-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10

Not received pulses at BLIN signalling LEDs PulseBLIN-L

START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9

| L10

Demand measures

Fixed demand period tFIX min 1 ... 60 step = 1

Rolling demand period tROL min 1 ... 60 step = 1

Number of cycles for rolling on demand N.ROL 1 ... 24 step = 1

Oscillography

Readings

State

Initialization | Start recording | Acquire | Trigger |

Stopped | Wait | Fail | Off

Records 0 ... 0 step = 0

Buffer storage % 0 ... 0 step = 0

Trigger Setup

Pre-trigger time s 0.05 ... 1.00 step = 0.01

Post-trigger time s 0.05 ... 60.00 step = 0.05

Element pickup trigger ON | OFF

Trigger from outputs K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10

Binary input trigger ON | OFF

Trigger from inputs IN1-IN32

IN1 | IN2 | IN3 | IN4 | IN5 | IN6 | IN7 | IN8 | IN9 |

IN10 | IN11 | IN12 | IN13 | IN14 | IN15 | IN16 | IN17

| IN18 | IN19 | IN20 | IN21 | IN22 | IN23 | IN24 |

IN25 | IN26 | IN27 | IN28 | IN29 | IN30 | IN31 | IN32

Trigger from inputs IN33-IN42

IN33 | IN34 | IN35 | IN36 | IN37 | IN38 | IN39 | IN40

| IN41 | IN42

80% Buffer alarm OFF | ON

Set sample channels

iL1 On | Off

iL2 On | Off

iL3 On | Off

iE On | Off

Set analog channels

Analog 1
