Thytronic NA10 User Manual

Timer 18 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 19 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 20 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 21 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 22 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 23 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 24 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Circuit Breaker supervision
LEDs-relays allocation
Open CB command relays CBopen-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Close CB command relays CBclose-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
CB Closed LEDs CBclose-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
CB Open LEDs CBopen-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
CB Diagnostic
Number of CB trips mode ModeN.Open OFF | ON
Number of CB trips threshold N.Open 0 ... 10000 step = 1
Cumulative CB tripping currents mode ModeSumI OFF | ON
Cumulative CB tripping currents threshold SumI In 0 ... 5000 step = 1
Cumulative CB tripping I^2t mode ModeSumI^2t OFF | ON
Circuit breaker opening time for I^2t calculation tbreak s 0.05 ... 1.00 step = 0.01
Cumulative CB tripping I^2t threshold SumI^2t In^2s 0 ... 5000 step = 1
CB operating time mode Mode-tOpen OFF | ON
Trigger relay for CB opening time trigger measurement Ktrig-break K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Circuit breaker maximum allowed opening time
Value s 0.05 ... 1.00 step = 0.01
Number of CB trips diagnostic relays N.Open-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Cumulative CB tripping currents diagnostic relays SumI-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Cumulative CB tripping I^2t diagnostic relays SumI^2t-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Circuit breaker opening time diagnostic relays tbreak-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Number of CB trips diagnostic LEDs N.Open-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Cumulative CB tripping currents diagnostic LEDs SumI-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Cumulative CB tripping I^2t diagnostic LEDs SumI^2t-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Circuit breaker opening time diagnostic LEDs tbreak-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
CT supervision - 74CT
74CT Enable 74CT Enable OFF | ON
74CT Threshold S< 0.10 ... 0.95 step = 0.01
74CT Overcurrent threshold
State OFF | ON
Pickup value In 0.10 ... 1.00 step = 0.01
S< Operating time
