FUNCTION CHARACTERISTICS
42
NA10 - Manual - 04 - 2022
Example 2
The residual CT primary current I
Enp
must be set as: I
Enp
= 100 A
• Measurement reading mode
Measures may be displayed according the following operating modes:
- With RELATIVE setting all measures are related to the nominal value,
- With PRIMARY setting all measures are related to the primary value.
Es2-IEn.ai
3x
K
TA
= 100A / 5A
52
I
En
= 5 A
