Thytronic NA10 User Manual

INSTALLATION
95
NA10 - Manual - 04 - 2022
Separate operator panel
The solution with projecting assembly and a separate operator panel is particularly suitable for
limited in depth installations.
Cutout dimension and mounting steps concerning the separate operator panel are the same for the
flushing mounting (see previous pages).
A standard direct shielded cable with RJ45 connectors must be used for connections.
Separate operator panel
Separate-mount.ai
F1
D1
RX
TX
F2
F3
F4
F5
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
C1 C2
C4
C3
C5 C6
C7 C8
E1
128.5
110
200 16820
30
5
1525
212.5
170
107
177
ON 41 32 5
TRIP
START
N.4 fori ø 4,5
B1
B2
B3
B4
B5
B6
B7
B8
Separate-mount1.ai
