SETTING UP YOUR SPEAKERS
The powered speaker system is designed for either bookshelf or stand mounting. The stands should be of rigid
construction, between 45 cm to 69 cm high and preferably have spikes.
The space between the two speakers and the distance from the listener is important. If the speakers are
positioned too close or too far apart, stereo imaging will not be fully developed.
Speakers are designed to perform optimally positioned at least 20 cm from the rear wall in an average listening
room. However, it may not be possible to install the speakers in this position and since rooms vary in shape, size,
and furnishing, a certain amount of experimentation is necessary to determine the most suitable position.
Moving the speakers very close to the rear wall will enhance the bass frequencies but will tend to reduce
soundstage depth, while moving the speakers away from the rear wall will tend to have the opposite effect. Avoid
positioning the speakers close to or in the corners of the room, as this will excite undesirable room coupling in
the low and middle frequencies. If the width of the rear wall is limited then toe-in the speakers slightly to reduce
reections. Room characteristics and positioning have a profound effect on the performance of the speakers, so
time and effort devoted to achieving the optimum positions will be rewarded.
Ensure that the ON/OFF Switch is in the OFF position.
Connect the two speakers together as shown below using the supplied speaker cable. Connect the RED (+)
and BLACK (−) terminals from the active speaker (left channel) to the corresponding terminals on the passive
speaker (right channel). If you wish to place your speakers further apart than the supplied cable will reach, we
recommend that you purchase a heavier gauge of speaker cable to minimize signal loss.
Follow the instructions on the ensuing pages to connect your audio sources to speakers. The examples in the
following pages are not meant to be exhaustive - just examples.
Connect the power cord from active speaker to the wall outlet.
Plus 2 Speakers Plus 3 Speakers
ATTENTION
When connecting audio cables the ON/OFF Switch must be turned OFF. After connecting all cables, the unit can
be turned ON.
When the volume is high, this system can produce noise levels that could permanently damage your hearing.
Plus speakers are a self-powered speaker system. Do not connect the speaker terminals to the speaker outputs
of a stereo amplier. Damage may occur. Use only the power cord provided with the speakers.
